Welded Mesh Fence
Product Name: Welded Mesh Fence
Model NO: WMF-001
Product Description :
 |
 |
|
- Type
- Specifications
- Packing
- Downloads
| Fence height | Dimensions panels | Number of reinforcements | Post length |
| (mm) | W x H (mm) | per panel | (mm) |
| 630 | 2500 x 630 | 2 | 1000 |
| 1030 | 2500 x 1030 | 2 | 1500 |
| 1230 | 2500 x 1230 | 3 | 1700 |
| 1530 | 2500 x 1530 | 3 | 2000 |
| 1730 | 2500 x 1730 | 3 | 2200 |
| 1930 | 2500 x 1930 | 3 | 2400 |
| 2030 | 2500 x 2030 | 4 | 2600 |
| 2430 | 2500 x 2430 | 4 | 3200 |
